| Attribute | Value |
|---|---|
| Single workable area | 350mm x 400mm |
| Double workable area | 750mm x 400mm |
| Plate positioning way | Fixture positioning, vision correction |
| Spindle motor speed | 60000rpm/min |
| Maximum cutting speed | 200mm/s |
| Max Moving Speed | 1000mm/s |
| Cutting repeat accuracy | 0.01mm |
| Cutting function | Straight line, slash, arcs, round |
| Machine size | 1550mm*1350mm*1450mm (With the display) |
| Model No | SSK-350 |
| Foot adjustable height | 60~100mm |
| Control motor type | RUKING-SEAZ-20LRCP |
| X Y Z's largest mobile area | 800mm x 450mm x 60mm |
| Plate thickness | <5mm |
| Cooling way | Since the cold |
| Replace the tool way | Special wrench to replace |
| Filtration system power | 2.2KW380V Motor |
| Power | 2KW AC220V |
| Air supply | 2~5KG/cm2 |
| Program memory | According to need to select the storage location |
| Configuration programming | CCD computar series high pixel color CCD |
| Dust collection | Lower dust and independent dust collection |
| Cutter diameter compensation | Automatic compensation |
| Shaft position accuracy | 0.001mm |
| Cutting accuracy | 0.02mm |
| Weight | About 750KG |
